Mini Cantilever Gate Roller
Designed primarily for compact cantilever gate systems using a 2-3/8 in outside-diameter support post and a 1-5/8 in outside-diameter gate rail. It may also be mounted to a compatible gate frame and used as a rear track roller in certain sliding or rolling gate systems, traveling with the gate along a fixed horizontal pipe track.
Current upgraded configuration
- Malleable iron body for dependable structural strength
- Hot-dip galvanized exterior finish for outdoor corrosion protection
- Upgraded stainless steel center fastener replaces the previous electro-galvanized fastener
- Bearing-supported roller movement for smooth gate travel
- Available as a single replacement roller or a 4-roller gate set
Technical Specifications
| Specification | Details |
|---|---|
| Support Post OD | 2-3/8 in |
| Gate Rail OD | 1-5/8 in |
| Roller Body Material | Malleable iron |
| Surface Finish | Hot-dip galvanized |
| Center Fastener | Stainless steel |
| Roller Movement | Bearing-supported |
| Primary Application | Compact cantilever gate systems |
| Additional Compatible Application | May be frame-mounted and used as a rear track roller in certain compatible sliding or rolling gate systems, traveling with the gate along a fixed horizontal pipe track |
| Available Quantities | 1 replacement roller; 4-, 8-, 12- or 16-roller options |
Check compatibility before ordering
Measure the outside diameter of both the fixed post and the moving gate rail. This model fits a 2-3/8 in post and a 1-5/8 in gate rail. Correct layout and alignment are required for a cantilever gate system.
For project quantities, custom configurations or technical questions, request a quote before ordering.
